4 Ply Webbing Sling

Heavy-duty eye and eye web sling otherwise known as 3 ply Webbing Slings feature a triplex webbing (triple thickness) ply to provide a heavier capacity than Single Ply Web Slings and Double Ply Web Slings

Proudly manufactured in the USA with lengths up to 20ft (larger offline) and capacities up to 88,000Lbs at 12" width in basket formation. Twisted Eyes at each end, please call for flat eyes.

Web Width	No. of Web Plys	Part Number	Vertical Capacity	Choker Capacity	V.Basket Capacity	Eye Length
1"	4	EE491	6,200Lbs	4,960Lbs	12,400Lbs	12"
2"	4	EE492	12,400Lbs	9,920Lbs	24,800Lbs	12"
3"	4	EE493	18,600Lbs	14,880Lbs	37,200Lbs	18"
4"	4	EE494	22,000Lbs	17,600Lbs	44,000Lbs	18"
6"	4	EE496	33,000Lbs	26,400Lbs	66,000Lbs	20"
8"	4	EE498	44,400Lbs	35,200Lbs	88,000Lbs	24"
10"	4	EE4910	55,000Lbs	44,000Lbs	110,000Lbs	28"
12"	4	EE4912	66,0000Lbs	52,800Lbs	132,000Lbs	32"

Minimum 5:1 safety design factor.

IMPORTANT: All of our Web Slings and Round Slings are manufactured on demand (extremely quickly) to your exect order, right here in Houston, TX. The date of manufacture is also printed on each sling label, for these reasons all sling sales are final and cannot be returned or exchanged once ordered.

• 4 Ply webbing
• Up to 20ft length
• Up to 132,000Lbs capacity at 12" width (V.Basket formation)
• Twisted eyes at each end
• Individually serial numbered
• Made in the USA
