Tandemloc Single Hook Type Forklift Attachment
Tandemloc Single Hook Type Forklift Attachments turn your forklift truck into a crane to securely lift single-point loads and rigging otherwise unable to be lifted by forks alone.
The single point central swivel hook with safety latch is efficiently protected by extended side plates against accidental damage caused to traditional Hook Type Forklift Accessories when lowering the forks or when the attachment is in storage. The extended side plates also enable the unit to remain stable when not in use.
Maximum security is achieved via the four (4) threaded T-bar screws that clamp against the sides of both forks and the retaining chain attachment point located above the hook, we recommend using a minimum Grade 30 chain as your safety chain to secure the attachment safely (chain not included).
With the Tandemloc Single Hook Type Forklift Attachment AS25 Series range you can choose between 2,000Lbs and 15,000Lbs capacities, 24" and 48" outer fork width as well as up to 6.25" individual fork width. Buy up to 20,000Lbs offline!
Â
| Model | WLL | "A" | Max Fork Height "B" | Max Fork Width "C" |
|---|---|---|---|---|
| AS25A02-24A-2PA | 2,000Lbs | 24" | 2.25" | 2.25" - 4.25" |
| AS25A02-36A-2PA | 2,000Lbs | 36" | 2.25" | 2.25" - 4.25" |
| AS25A04-36A-2PA | 4,000Lbs | 36" | 2.25" | 2.25" - 4.25" |
| AS25A06-24A-2PA | 6,000Lbs | 24" | 2.25" | 2.25" - 4.25" |
| AS25A06-36A-2PA | 6,000Lbs | 36" | 2.25" | 2.25" - 4.25" |
| AS25A10-24A-2PA | 10,000Lbs | 24" | 2.25" | 3.25 - 6.25" |
| AS25A10-36A-2PA | 10,000Lbs | 36" | 2.25" | 3.25 - 6.25" |
| AS25A10-48A-2PA | 10,000Lbs | 48" | 2.25" | 3.25 - 6.25" |
| AS25A15-24A-2PA | 15,000Lbs | 24" | 2.25" | 3.25 - 6.25" |
| AS25A15-36A-2PA | 15,000Lbs | 36" | 2.25" | 3.25 - 6.25" |
| AS25A15-48A-2PA | 15,000Lbs | 48" | 2.25" | 3.25 - 6.25" |
| AS25A20-24-2PA | 20,000Lbs | 24" | 3.25" | 3.25 - 6.25" |
| AS25A20-28A-2PA | 20,000Lbs | 28" | 3.25" | 3.25 - 6.25" |
| AS25A20-36A-2PA | 20,000Lbs | 36" | 3.25" | 3.25 - 6.25" |
| AS25A20-48A-2PA | 20,000Lbs | 48" | 3.25" | 3.25 - 6.25" |
- Fits to both fork tines
- 5-point security on most models
- Innovative design focused on safety, usability and longevity
- Low headroom design
- Swivellig hook with spring-loaded safety catch
- Extended side plates allow the unit to be stable when not in use
Original: $843.51
-65%$843.51
$295.23
Description
Tandemloc Single Hook Type Forklift Attachments turn your forklift truck into a crane to securely lift single-point loads and rigging otherwise unable to be lifted by forks alone.
The single point central swivel hook with safety latch is efficiently protected by extended side plates against accidental damage caused to traditional Hook Type Forklift Accessories when lowering the forks or when the attachment is in storage. The extended side plates also enable the unit to remain stable when not in use.
Maximum security is achieved via the four (4) threaded T-bar screws that clamp against the sides of both forks and the retaining chain attachment point located above the hook, we recommend using a minimum Grade 30 chain as your safety chain to secure the attachment safely (chain not included).
With the Tandemloc Single Hook Type Forklift Attachment AS25 Series range you can choose between 2,000Lbs and 15,000Lbs capacities, 24" and 48" outer fork width as well as up to 6.25" individual fork width. Buy up to 20,000Lbs offline!
Â
| Model | WLL | "A" | Max Fork Height "B" | Max Fork Width "C" |
|---|---|---|---|---|
| AS25A02-24A-2PA | 2,000Lbs | 24" | 2.25" | 2.25" - 4.25" |
| AS25A02-36A-2PA | 2,000Lbs | 36" | 2.25" | 2.25" - 4.25" |
| AS25A04-36A-2PA | 4,000Lbs | 36" | 2.25" | 2.25" - 4.25" |
| AS25A06-24A-2PA | 6,000Lbs | 24" | 2.25" | 2.25" - 4.25" |
| AS25A06-36A-2PA | 6,000Lbs | 36" | 2.25" | 2.25" - 4.25" |
| AS25A10-24A-2PA | 10,000Lbs | 24" | 2.25" | 3.25 - 6.25" |
| AS25A10-36A-2PA | 10,000Lbs | 36" | 2.25" | 3.25 - 6.25" |
| AS25A10-48A-2PA | 10,000Lbs | 48" | 2.25" | 3.25 - 6.25" |
| AS25A15-24A-2PA | 15,000Lbs | 24" | 2.25" | 3.25 - 6.25" |
| AS25A15-36A-2PA | 15,000Lbs | 36" | 2.25" | 3.25 - 6.25" |
| AS25A15-48A-2PA | 15,000Lbs | 48" | 2.25" | 3.25 - 6.25" |
| AS25A20-24-2PA | 20,000Lbs | 24" | 3.25" | 3.25 - 6.25" |
| AS25A20-28A-2PA | 20,000Lbs | 28" | 3.25" | 3.25 - 6.25" |
| AS25A20-36A-2PA | 20,000Lbs | 36" | 3.25" | 3.25 - 6.25" |
| AS25A20-48A-2PA | 20,000Lbs | 48" | 3.25" | 3.25 - 6.25" |
- Fits to both fork tines
- 5-point security on most models
- Innovative design focused on safety, usability and longevity
- Low headroom design
- Swivellig hook with spring-loaded safety catch
- Extended side plates allow the unit to be stable when not in use
