Vestil Dock Barricades
The Dock Barricade is an active barrier that represents the next generation of innovative loading dock safety systems. The electric/hydraulic power unit provides quick and effortless operation. It can stop a four thousand (4,000) pound loaded truck at four (4) miles per hour. It is electronically operated and consists of an electrical bumper-style safety stop circuit to sense obstructions when lowering. Installation is simple, anchor the unit to the floor, and plug in. Mechanical unit, model DJG-100MW, features a manual hand crank winch to raise/lower barricade arm. All units include a lock bar on the arm post to restrict rotation of the barricade arm, padlock is NOT included. 115V 1-Phase standard
| Dock Barricade | ||||||
| Model | Operation | Door Size (W x H) |
Arm Height Raised | Arm Height Lowered | Overall (WxL) |
Wt. (lbs) |
| DJG-100 | Electric | 8' x 8' | 148-5/8" | 28-1/2" | 24"x130-3/4" | 686 |
| DJG-100-10 | Electric | 10' x 10' | 172-5/8" | 28-1/2" | 24"x154-3/4" | 753 |
| DJG-100MW | Mechanical Winch | 8' x 8' | 149" | 32" | 24"x133-1/4" | 539 |
Original: $3,019.26
-65%$3,019.26
$1,056.74
Description
The Dock Barricade is an active barrier that represents the next generation of innovative loading dock safety systems. The electric/hydraulic power unit provides quick and effortless operation. It can stop a four thousand (4,000) pound loaded truck at four (4) miles per hour. It is electronically operated and consists of an electrical bumper-style safety stop circuit to sense obstructions when lowering. Installation is simple, anchor the unit to the floor, and plug in. Mechanical unit, model DJG-100MW, features a manual hand crank winch to raise/lower barricade arm. All units include a lock bar on the arm post to restrict rotation of the barricade arm, padlock is NOT included. 115V 1-Phase standard
| Dock Barricade | ||||||
| Model | Operation | Door Size (W x H) |
Arm Height Raised | Arm Height Lowered | Overall (WxL) |
Wt. (lbs) |
| DJG-100 | Electric | 8' x 8' | 148-5/8" | 28-1/2" | 24"x130-3/4" | 686 |
| DJG-100-10 | Electric | 10' x 10' | 172-5/8" | 28-1/2" | 24"x154-3/4" | 753 |
| DJG-100MW | Mechanical Winch | 8' x 8' | 149" | 32" | 24"x133-1/4" | 539 |
