Vestil Low Profile Scissor Cart w/ Auto-Shift
In areas of congestion a low profile scissor cart is a must. With a two speed foot pump, the platform is easily raised/lowered to the desired position. Not only is this design extremely efficient but also ergonomically friendly. With a raised steering handle the user can maintain a proper working posture during transit. The sleek steel design, with a powder coated finish for baked in added toughness, is simple to clean and limits needless scuffs or abrasions. Mold on rubber casters with brakes roll easily over a variety of surfaces. Auto-Shift is a two-speed pump that automatically shifts between speeds based on the output pressure of the hydraulic system. Internal features of the pump include primary pressure relief and pressure compensated return-flow mechanisms, an integrated lowering valve, and an auto-shifting valve assembly. The pump also utilizes replaceable sleeve bearings, valve components, and seals to simplify maintenance requirements and maximize service life.
| Low Profile Scissor Carts w/ Auto-Shift | |||||
| Model | Platform Size (WxL) |
Overall Size (LxWxH) |
Service Range |
Uniform Capacity (lbs) |
Wt. (lbs) |
| CART-200-LP-AS | 17-3/4"x27-1/2" | 44-1/8"x17-3/4"x34-5/8" | 3-1/2" - 23-5/8" | 200 | 186 |
| CART-400-LP-AS | 19-5/8"x32-1/4" | 48-7/8"x19-5/8"x34-5/8" | 3-1/2" - 23-5/8" | 400 | 312 |
| CART-900-LP-AS | 23-5/8"x35-1/2" | 52-1/8"x23-5/8"x34-5/8" | 3-1/2" - 23-5/8" | 900 | 310 |
Original: $973.10
-65%$973.10
$340.58
Description
In areas of congestion a low profile scissor cart is a must. With a two speed foot pump, the platform is easily raised/lowered to the desired position. Not only is this design extremely efficient but also ergonomically friendly. With a raised steering handle the user can maintain a proper working posture during transit. The sleek steel design, with a powder coated finish for baked in added toughness, is simple to clean and limits needless scuffs or abrasions. Mold on rubber casters with brakes roll easily over a variety of surfaces. Auto-Shift is a two-speed pump that automatically shifts between speeds based on the output pressure of the hydraulic system. Internal features of the pump include primary pressure relief and pressure compensated return-flow mechanisms, an integrated lowering valve, and an auto-shifting valve assembly. The pump also utilizes replaceable sleeve bearings, valve components, and seals to simplify maintenance requirements and maximize service life.
| Low Profile Scissor Carts w/ Auto-Shift | |||||
| Model | Platform Size (WxL) |
Overall Size (LxWxH) |
Service Range |
Uniform Capacity (lbs) |
Wt. (lbs) |
| CART-200-LP-AS | 17-3/4"x27-1/2" | 44-1/8"x17-3/4"x34-5/8" | 3-1/2" - 23-5/8" | 200 | 186 |
| CART-400-LP-AS | 19-5/8"x32-1/4" | 48-7/8"x19-5/8"x34-5/8" | 3-1/2" - 23-5/8" | 400 | 312 |
| CART-900-LP-AS | 23-5/8"x35-1/2" | 52-1/8"x23-5/8"x34-5/8" | 3-1/2" - 23-5/8" | 900 | 310 |
