Renfroe M Locking Type Lifting Clamps
If lifting, positioning, sorting, erecting, and handling of prefabricated sections is part of your daily tasks, then Renfroe's Model M Locking Type Lifting Clamps simply ticks all the boxes.
Engineered with a split lower jaw which enables the clamp to be particularly useful when handling structural shapes, the Model M incorporates Renfroe's signature 'Lock Closed' design that facilitates attaching the clamp to the item being lifted.
Designed to be used in pairs, sets of pairs, or in a tripod arrangement, the Model M Lifting Clamp is available in working load limits from 0.5tons right up to 8tons.
NOTE: MUST BE USED IN PAIRS
|
SKU |
Capacity (tons) |
Shackle Hole Dia (in.) |
Weight (lbs) |
Min Jaw Open (in.) |
Max Jaw Open (in.) |
Clamp Height (in.) |
Clamp Width (in.) |
Jaw Height (in.) |
Jaw Length (in.) |
Overall Clamp Height (in.) |
Overall Clamp Length (in.) |
|
M-00.50-A |
0.5 |
2.25 |
7 |
0 |
1 |
4.6875 |
2.625 |
1.4375 |
2.3125 |
8.875 |
7.0625 |
|
M-00.50-B |
0.5 |
2.25 |
8 |
0.75 |
1.5 |
5.1875 |
2.625 |
1.4375 |
2.3125 |
9.375 |
7.0625 |
|
M-00.50-C |
0.5 |
2.25 |
9 |
1.25 |
2 |
5.6875 |
2.625 |
1.4375 |
2.3125 |
9.875 |
70.625 |
|
M-01.00-A |
1 |
2.25 |
11 |
0 |
1 |
5.5 |
2.75 |
1.875 |
2.5 |
9.5 |
8.125 |
|
M-01.00-B |
1 |
2.25 |
12 |
0.75 |
1.5 |
6 |
2.75 |
1.875 |
2.5 |
10 |
8.125 |
|
M-01.00-C |
1 |
2.25 |
1 |
1.25 |
2 |
6.5 |
2.75 |
1.875 |
2.5 |
10.5 |
8.125 |
|
M-02.00-A |
2 |
3.0625 |
23 |
0 |
1.25 |
6.5625 |
3.875 |
2 |
3.1875 |
12.125 |
10.75 |
|
M-02.00-B |
2 |
3.0625 |
24 |
1 |
2 |
7.1875 |
3.875 |
2 |
3.1875 |
12.875 |
10.75 |
|
M-02.00-C |
2 |
3.0625 |
27 |
1.75 |
2.75 |
7.9375 |
3.875 |
2 |
3.1875 |
13.625 |
10.75 |
|
M-04.00-A |
4 |
3.625 |
36 |
0 |
1.5 |
7.75 |
4.375 |
2.75 |
3.8125 |
14.5 |
12 |
|
M-04.00-B |
4 |
3.625 |
38 |
1.25 |
2.5 |
8.75 |
4.375 |
2.75 |
3.8125 |
16.5 |
12 |
|
M-04.00-C |
4 |
3.625 |
41 |
2.25 |
3.5 |
9.75 |
4.375 |
2.75 |
3.8125 |
14.5 |
12 |
|
M-08.00-A |
8 |
4 |
110 |
0 |
2 |
12.9375 |
5.5 |
4 |
4.9375 |
21 |
0 |
|
M-08.00-B |
8 |
4 |
110 |
1.75 |
3.5 |
13.9375 |
5.5 |
4 |
4.9375 |
21 |
0 |
|
M-08.00-C |
8 |
4 |
125 |
3.25 |
5 |
14.4375 |
5.5 |
4 |
4.9375 |
22.5 |
0 |
Original: $765.00
-65%$765.00
$267.75
